PG2214TB

Data Sheet

GaAs Integrated Circuit for L, S-Band SPDT Switch

etc.

? W-LAN, WLL and Bluetooth

A Business Partner of Renesas Electronics Corporation.

Preliminary

R09DS0050EJ0400

Rev.4.00

Sep 10, 2012

DESCRIPTION

The PG2214TB is a GaAs MMIC for L, S-band SPDT (Single Pole Double Throw) switch which was developed for

mobile phone and another L, S-band application.

This device can operate 2 control switching by control voltage 1.8 to 5.3 V. This device can operate frequency from

0.05 to 3.0 GHz, having the low insertion loss and high isolation.

This device is housed in a 6-pin super minimold package. And this package is able to high-density surface mounting.

FEATURES

? Switch control voltage : V cont (H) = 1.8 to 5.3 V (3.0 V TYP.)

: V cont (L) = ? 0.2 to +0.2 V (0 V TYP.)

? Low insertion loss : L ins1 = 0.25 dB TYP. @ f = 0.05 to 0.5 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: L ins2 = 0.25 dB TYP. @ f = 0.5 to 1.0 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: L ins3 = 0.30 dB TYP. @ f = 1.0 to 2.0 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: L ins4 = 0.35 dB TYP. @ f = 2.0 to 2.5 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: L ins5 = 0.35 dB TYP. @ f = 2.5 to 3.0 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

? High isolation : ISL1 = 32 dB TYP. @ f = 0.05 to 0.5 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: I S L 2 = 2 8 d B T Y P . @ f = 0 . 5 t o 1 . 0 G H z , V cont (H) = 3.0 V, V cont (L) = 0 V

: I S L 3 = 2 7 d B T Y P . @ f = 1 . 0 t o 2 . 0 G H z , V cont (H) = 3.0 V, V cont (L) = 0 V

: I S L 4 = 2 6 d B T Y P . @ f = 2 . 0 t o 2 . 5 G H z , V cont (H) = 3.0 V, V cont (L) = 0 V

: I S L 5 = 2 4 d B T Y P . @ f = 2 . 5 t o 3 . 0 G H z , V cont (H) = 3.0 V, V cont (L) = 0 V

? Handling power : P in (1 dB) = +27.0 dBm TYP. @ f = 0.5 to 3.0 GHz, V cont (H) = 3.0 V, V cont (L) = 0 V

: P in (1 dB) = +20.0 dBm TYP. @ f = 0.5 to 3.0 GHz, V cont (H) = 1.8 V, V cont (L) = 0 V

? High-density surface mounting : 6-pin super minimold package (2.0 × 1.25 × 0.9 mm)

APPLICATIONS

? L, S-band digital cellular or cordless telephone

<R>

ORDERING INFORMATION

P a r t N u m b e r

PG2214TB-E4

P a c k a g e

6-pin super minimold (2012)

(Pb-Free)

M a r k i n g

G4J

S u p p l y i n g F o r m

? Embossed tape 8 mm wide

? Pin 4, 5, 6 face the perforation side of the tape

? Qty 3 kpcs/reel

Remark To order evaluation samples, contact your nearby sales office.

Part number for sample order: PG2214TB-A

Caution Observe precautions when handling because these devices are sensitive to electrostatic discharge.

The mark <R> shows major revised points.

The revised points can be easily searched by copying an "<R>" in the PDF file and specifying it in the "Find what:" field.

R 0 9 D S 0 0 5 0 E J 0 4 0 0 R e v . 4 . 0 0

Sep 10, 2012

P a g e 1 o f 1 2
